Cheap Automatic Shrink Stretch Pallet Wrapping Machine Film Packing Pallet Wrapper
Advantage:
1.PLC integrated machine control is more reliable, winding layer number and times can be changed;
2.Photoelectric switch self-dynamic Sense measurement of the height of the goods;
3.Random reinforcement winding function, can carry on the special protection to the Part of Cargos;
4.Overhead time setting function;
Rotary table drive:
5.The turntable frequency conversion speed regulation is adjustable from 0 to 15 RPM;
6.Turntable automatic reset;
Membrane system:
7..Membrane frame dynamic prestretching mechanism, prestretching up to 250%;
8.The rising and descending speed of the membrane frame can be adjusted respectively, and the membrane feeding speed can be adjusted.
| Control system | PLC control system |
| Photo eye pallet height sensor | |
| 3-12 RPM variable turntable speed by frequency changer | |
| Film carriage | Powered pre-stretch system to 300% to min film consumption |
| Film delivery barlable speed by spparate AC Drive Motor | |
| Heavy duty double-chain carriage lift, calm and safety | |
| Technology Data | Max load size(mm): 1200(L)X1200(W)X2400(H) |
| Turntable dia: 1650mm | |
| Turntable Height: 77mm | |
| Turntable weight capacity: 2000kgs | |
| Turntable speed: 3-12rpm | |
| Electrics: 220V 50HZ 1 phase | |
| Power: 1.5KW |
Pallet Wrappers in Dispatch Operations Significantly Increase Output, Eliminate Worker Strain and Reduce the Likelihood of Damaged in Transit. We Offer a Range of Pallet Wrappers from Base Models Through to Fully Automatic Models, and are Fully Customized with a Variety of Optional Functions to Meet the Various Requirements of Customers.
